CJWA Basic Series Twin Screw Extruder

Place of Origin:

China

Brand Name:

Jwell

Certification:

ISO CE

INQUIRY
  • Details
  • Factory Video
  • Competitive Advantage
  • Packing & Shipping

Description:

CJWA series twin-screw extruder is defined as regular torque type. It is used in a large number of conventional modification operations and some low-viscosity and high-melting materials. It has strong practicability, high cost effective and stable performance.



Specifications:

Model

Diameter(mm)

L/D

Screw Speed(rpm/min)

Motor power(kw)

Torque per shaft(N.m)

Specific torque(T/A3)

Capacity range(kg/hr)

CJWA35

35.6

24-68

600

18.5

149

6

50-100

CJWA40

41.1

24-68

600

30

226

6

75-150

CJWA52

51.4

24-68

600

55

437

6

140-280

CJWA65

62.4

24-68

600

110

773

6

280-560

CJWA75

71.0

24-68

600

160

1188

6

400-800

CJWA85

81.0

24-68

600

220

1714

6

550-1100

CJWA95

93.0

24-68

600

350

2610

6

880-1760

CJWA110

108.0

24-68

500

450

4010

6

1100-2200

CJWA120

120.0

24-68

500

600

5500

6

1500-3000

CJWA135

132.0

24-68

400

650

7321

6

1600-3200

Note:The specifications are subject to change without prior notice.

1. Jwell is the largest plastic extrusion machine manufacturer in China.We work closely with world famous brand , your equipment can also be equipped with  any component brand you wish .

2. Jwell has twin parrel screw extrusion test line and single screw test line . Our test lab support you test under realistic production conductions as well as further enhance your processing technology through our test and help you choose the right type of equipment .

3. Working with Jwell you can be confident that your service and maintenance requirements will be correctly documented and that you have exactly the right resources and skills in place before start-up. Our experienced team will work with you to identify the people, resources and process documentation you will need to support your maintenance activities.
4. Jwell provides technical, driving and systems training to employees and engineers from supplier from all over the world.

All the machines are packaged by our professional team, will be packed by wooden pallet. For some important spare parts, we will pack with the wooden box.
